Battery module laser welding machine
Category:Battery module laser welding machine
Widely used in laser welding of new energy batteries, the entire system can seamlessly connect upstream and downstream processes according to customer requirements, achieving efficient unmanned management. It can also collect data on related processes according to customer requirements for Industry 4.0.

Phone:+86 180 6825 4557

Mail:he@dxh-laser.com

Product Features

1. Specially designed for the new energy battery industry, dedicated to dedicated aircraft

2. The welding method can be either galvanometer or continuous welding

3. Adopting a gantry dual drive structure, fast speed and high precision

4. Independently developed and designed clamp module with strong universality

5. Automatic cutting structure, convenient and fast


Application field

Widely used in laser welding of new energy batteries, the entire system can seamlessly connect upstream and downstream processes according to customer requirements, achieving efficient unmanned management. It can also collect data on related processes according to customer requirements for Industry 4.0.



Technical Specifications

设备名称

DXH-电池模组激光焊接机

激光功率

1000-4000W

激光波长1080nm
工作方式连续/点焊
流水线及自动 上下料机构大鑫华定制
测高系统基恩士
最大焊接范围(mm

) 1000x600x400

焊接速度

0-500mm/s

空跳速度

0-2000mm/s

重复定位进度

±0.02mm

工作环境

5~40℃、湿度<70%、无凝露

适用板厚小于5mm
电力需求

220V、50Hz/380V、50Hz

设备尺寸

L:3000*W:1500*H:2200

整机重量≈600Kg
